Power Supply
LED drivers are specifically engineered to provide a reliable and efficient power supply to your LED lighting fixtures, ensuring they operate at their best. Ideal for maintaining the longevity and brightness of your lights, these drivers are a crucial component in any modern lighting setup.
Our kitchen lighting products, such as the LED Drivers, ensure efficient operation and compatibility. Enhance control with our Smart Drivers, allowing easy adjustments to your kitchen’s ambience.
Available in 12V, 60W/150W Drivers
150W 12V
150W LED Driver Specification |
GSK19 |
||
|
|||
Product Picture |
Wattage: 150W |
|
|
|
|||
|
|||
Input parameter |
Input voltage |
AC220-240V 50/60Hz |
|
Input power |
140W±5% Carrying load10.5A/220-240V AC |
||
Power factor |
PF:0.5 Carrying load10.5A/220-240V AC |
||
Power efficiency |
≥90% Carrying load10.5A/220-240V AC |
||
Dimming mode |
Touch/Gate/Film |
||
Output parameters |
Full load voltage |
12V±3% Carrying load10.5A/220-240V AC |
|
Output current |
MAX:10.5A |
||
No-load voltage |
12V±3% |
||
Output power |
126W±3% Carrying load10.5A 220-240V AC |
||
Output Load adjustment rate |
＜3% |
||
Input linear adjustment rate |
＜3% |
||
Turn on Delay Time |
＜1.0S Carrying load10.5A 220-240V AC |
||
|
|||
Protection characteristics |
Short circuit protection |
■yes；Stop working and resume automatic release. |
|
Open road protection |
■yes； |
||
Overload protection |
■yes；≥14AHiccup, automatically relieved upon recovery. |
||
Surge protection |
■1500V |
||
Environmental Science |
Working environment temperature |
■-15～45℃ 20-90%RH |
|
Waterproof grade |
■IP20 |
||
Security |
Absolute green resistance |
>100MΩ |
|
Dielectric strength |
■1500V Input to output |
||
Conforming to standard |
Safety standards |
\ |
|
EMC |
\ |
||
Packing |
Size |
256*53*19mm |
|
Enclosure |
\ |
||
Pack |
\ |
||
Life |
Warranty |
3 Years |
|
|
|||
1. Operating Conditions：-15~40℃．20-90%RH |
|||
2. Operating Conditions：-40 ~ +50℃, 10 ~ 70% RH |
|||
|
|||
60W 12V
60W LED Driver Specification |
GSK03 |
||
|
|||
Product Picture |
Wattage: 60W |
|
|
|
|||
|
|||
Input parameter |
Input voltage |
AC220-240V 50/60Hz |
|
Input power |
60W±5% Carrying load4.5A/220-240V AC |
||
Power factor |
PF:0.5 Carrying load4.5A/220-240V AC |
||
Power efficiency |
≥88% Carrying load4.5A/220-240V AC |
||
Dimming mode |
Touch/Gate/Film |
||
Output parameters |
Full load voltage |
12V±3% Carrying load4.5A/220-240V AC |
|
Output current |
MAX:4.8A |
||
No-load voltage |
12V±3% |
||
Output power |
55W±3% Carrying load4.5A 220-240V AC |
||
Output Load adjustment rate |
＜3% |
||
Input linear adjustment rate |
＜3% |
||
Turn on Delay Time |
＜1.0S Carrying load4.5A 220-240V AC |
||
|
|||
Protection characteristics |
Short circuit protection |
■Yes; Stop working and resume automatic release. |
|
Open road protection |
■Yes； |
||
Overload protection |
■Yes；≥5.2AHiccup, automatically relieved upon recovery. |
||
Surge protection |
■1500V |
||
Environmental Science |
Working environment temperature |
■-15～45℃ 20-90%RH |
|
Waterproof grade |
■IP20 |
||
Security |
Absolute green resistance |
>100MΩ |
|
Dielectric strength |
■1500V Input to output |
||
Conforming to standard |
Safety standards |
\ |
|
EMC |
\ |
||
Packing |
Size |
184*53*19mm |
|
Enclosure |
\ |
||
Pack |
\ |
||
Life |
Warranty |
3 Years |
|
|
|||
1. Operating Conditions：-15~40℃．20-90%RH |
|||
2. Operating Conditions：-40 ~ +50℃, 10 ~ 70% RH |
|||
|
|||
